Skupina artiklov
Cep z notranjim stisnjenim koncem
Materials:
Bodies: Copper/copper alloy, type stainless steel: 1.4404,Seals: FKM (red)
Temperature range*:
-20 do +200 °C (depending on medium), temporarily maks. +280 °C
Operating pressure:
Type copper / copper alloy: 16 bar, Vacuum up to -0.8 bar, Type stainless steel: Ø 15 - 22: 40 bar, Ø 28 - 35: 25 bar, Ø 42 - 54: 16 bar, all diameters: technical gases (for example compressed air, argon, nitrogen, carbon dioxide): 16 bar, Vacuum up to -0.8 bar
Fields of application:
Compressed air, neutral gases, cooling water, industrial water, heating water, heating oil facilities, thermal solar systems with glycol or glycol-water mixture
Advantages:
•thanks to the FKM seal also suitable for oil bearing compressed air and water/glycol mixtures,
•can be pressed using all standard die sets and slings, which correspond to the original pressing contours M, V and SA,
•use with standard EN 1057 copper tubing (copper/copper alloy type),
•Use with our stainless steel system pipe 1.4404 manufactured according to DIN EN 10312 (Stainless steel type)
•can be pressed using all standard die sets and slings, which correspond to the original pressing contours M, V and SA,
•use with standard EN 1057 copper tubing (copper/copper alloy type),
•Use with our stainless steel system pipe 1.4404 manufactured according to DIN EN 10312 (Stainless steel type)
Warning:
Crimped fittings made of C steel are not suitable for compressed air lines due to the risk of corrosion. We therefore do not offer them.
*due to the variety of applications, the following excerpt lists the max. temperature values: <br>compressed air, heating oil, water (without additives): -20°C to max. +120°C <br>glycol-water mixture, glycol: -20°C to max. +200°C (temporary up to max. +280°C)
Dokumenti:
Več informacij
Filtriraj artikle
Cep z notranjim stisnjenim koncem:
14 od 14 izdelkov
11,89 €
z DDV
12,97 €
z DDV
17,18 €
z DDV
26,29 €
z DDV
29,54 €
z DDV
45,76 €
z DDV
78,86 €
z DDV
PVK 15 ES
Crimped fitting, end cap, 15mm, 1.4404
18,77 €
z DDV
PVK 18 ES
Crimped fitting, end cap, 18mm, 1.4404
22,60 €
z DDV
PVK 22 ES
Crimped fitting, end cap, 22mm, 1.4404
24,43 €
z DDV
PVK 28 ES
Crimped fitting, end cap, 28mm, 1.4404
29,26 €
z DDV
PVK 35 ES
Crimped fitting, end cap, 35mm, 1.4404
40,91 €
z DDV
PVK 42 ES
Crimped fitting, end cap, 42mm, 1.4404
88,99 €
z DDV
PVK 54 ES
Crimped fitting, end cap, 54mm, 1.4404
97,94 €
z DDV
Vse navedbe podatkov so nezavezujoče orientacijske vrednosti! Za izbiro podatkov, za katere ne izdamo pisnega potrdila, ne prevzemamo jamstev. Navedbe tlaka, v kolikor ni navedeno drugače, se nanašajo na tekočine skupine II. pri +20°C.
