Item group

Pressure regulator - Solid, to 2800 l/min*

Flow:

Kv value 3 m³/h, 2800 l/min* (brass: Kv value 3 m³/h, 2500 l/min*)

Version:

Self-relieving (with secondary vent), optionally non-relieving

Materials:

Seals: FKM, membrane: NBR (PTFE-coated)

Temperature range:

-20 to +80 °C

Media:

oiled and unoiled compressed air, non-toxic gasses (with option -NB: Gasses and liquids, demineralised water, with option -NE: aggressive gasses (not for piston type regulator), with option -CO: CO2 (only for brass type)

Pressure gauge connection:

G 1/4"

Switch panel thread:

M 45x1.5 (brass: M 50x1.5)

Optional:

Version non-reversible for gases and liquids (NBR membrane, PTFE-coated), -NB, Version non-reversible for aggressive gases (stainless steel membrane) -NE, Version non-reversible with EPDM seals for CO2 (only for type brass) CO
*At 8 bar inlet pressure, 6 bar outlet pressure and 1 bar pressure drop, **piston pressure regulator

Documents:

More information Less information

Filter items

exécution
Please select
Tension de commande
Please select
Fonction
Please select
Filetage
Please select
more filters
Pressure regulator - Solid, to 2800 l/min*:
20 of 36 articles
pressure regulator, 1.4404, G 1/2", 0,1 to 1,5bar (Standard)(R 12-1,5 ES)
R 12-1,5 ES
pressure regulator, 1.4404, G 1/2", 0,1 to 1,5bar (Standard)
€985.11 incl. VAT
Immediately available
pressure regulator, 1.4404, G 1/2", 0,2 to 3bar (Standard)(R 12-3 ES)
R 12-3 ES
pressure regulator, 1.4404, G 1/2", 0,2 to 3bar (Standard)
€985.11 incl. VAT
Immediately available
pressure regulator, 1.4404, G 1/2", 0,5 to 8bar (Standard)(R 12-8 ES)
R 12-8 ES
pressure regulator, 1.4404, G 1/2", 0,5 to 8bar (Standard)
€1,007.78 incl. VAT
Immediately available
pressure regulator, 1.4404, G 1/2", 1 to 15bar (Standard)(R 12-15 ES)
R 12-15 ES
pressure regulator, 1.4404, G 1/2", 1 to 15bar (Standard)
€1,007.78 incl. VAT
Immediately available
pressure regulator, 1.4404, G 1/2", 2 to 30bar (Standard)(R 12-30 ES)
R 12-30 ES **
pressure regulator, 1.4404, G 1/2", 2 to 30bar (Standard)
€1,576.54 incl. VAT
Immediately available
pressure regulator, 1.4404, G 1/2", 3 to 50bar (Standard)(R 12-50 ES)
R 12-50 ES **
pressure regulator, 1.4404, G 1/2", 3 to 50bar (Standard)
€1,576.54 incl. VAT
Immediately available
pressure regulator, Brass, G 1/2", 0,1 to 1,5bar (Standard)(R 12-1,5 MS)
R 12-1,5 MS
pressure regulator, Brass, G 1/2", 0,1 to 1,5bar (Standard)
€382.22 incl. VAT
Immediately available
pressure regulator, Brass, G 1/2", 0,2 to 3bar (Standard)(R 12-3 MS)
R 12-3 MS
pressure regulator, Brass, G 1/2", 0,2 to 3bar (Standard)
€382.22 incl. VAT
Immediately available
pressure regulator, Brass, G 1/2", 0,5 to 8bar (Standard)(R 12-8 MS)
R 12-8 MS
pressure regulator, Brass, G 1/2", 0,5 to 8bar (Standard)
€382.22 incl. VAT
Immediately available
pressure regulator, Brass, G 1/2", 1 to 15bar (Standard)(R 12-15 MS)
R 12-15 MS
pressure regulator, Brass, G 1/2", 1 to 15bar (Standard)
€382.22 incl. VAT
Immediately available
pressure regulator, Brass, G 1/2", 2 to 30bar (Standard)(R 12-30 MS)
R 12-30 MS **
pressure regulator, Brass, G 1/2", 2 to 30bar (Standard)
€499.04 incl. VAT
Immediately available
pressure regulator, Brass, G 1/2", 3 to 50bar (Standard)(R 12-50 MS)
R 12-50 MS **
pressure regulator, Brass, G 1/2", 3 to 50bar (Standard)
€499.04 incl. VAT
Immediately available
pressure regulator, 1.4404, G 1/2", 0,1 to 1,5bar (non-relieving)(R 12-1,5 ES-NB)
R 12-1,5 ES-NB
pressure regulator, 1.4404, G 1/2", 0,1 to 1,5bar (non-relieving)
€985.11 incl. VAT
Immediately available
pressure regulator, 1.4404, G 1/2", 0,2 to 3bar (non-relieving)(R 12-3 ES-NB)
R 12-3 ES-NB
pressure regulator, 1.4404, G 1/2", 0,2 to 3bar (non-relieving)
€985.11 incl. VAT
Immediately available
pressure regulator, 1.4404, G 1/2", 0,5 to 8bar (non-relieving)(R 12-8 ES-NB)
R 12-8 ES-NB
pressure regulator, 1.4404, G 1/2", 0,5 to 8bar (non-relieving)
€985.11 incl. VAT
Immediately available
pressure regulator, 1.4404, G 1/2", 1 to 15bar (non-relieving)(R 12-15 ES-NB)
R 12-15 ES-NB
pressure regulator, 1.4404, G 1/2", 1 to 15bar (non-relieving)
€985.11 incl. VAT
Immediately available
pressure regulator, 1.4404, G 1/2", 2 to 30bar (non-relieving)(R 12-30 ES-NB)
R 12-30 ES-NB **
pressure regulator, 1.4404, G 1/2", 2 to 30bar (non-relieving)
€1,576.54 incl. VAT
Immediately available
pressure regulator, 1.4404, G 1/2", 3 to 50bar (non-relieving)(R 12-50 ES-NB)
R 12-50 ES-NB **
pressure regulator, 1.4404, G 1/2", 3 to 50bar (non-relieving)
€1,576.54 incl. VAT
Immediately available
pressure regulator, Brass, G 1/2", 0,1 to 1,5bar (non-relieving)(R 12-1,5 MS-NB)
R 12-1,5 MS-NB
pressure regulator, Brass, G 1/2", 0,1 to 1,5bar (non-relieving)
€382.22 incl. VAT
Immediately available
pressure regulator, Brass, G 1/2", 0,2 to 3bar (non-relieving)(R 12-3 MS-NB)
R 12-3 MS-NB
pressure regulator, Brass, G 1/2", 0,2 to 3bar (non-relieving)
€382.22 incl. VAT
Immediately available
All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
