Item group

Pneumatic cylinder switch for round cylinder up to Ø 100, Type H

Exemplary representation: Pneumatic cylinder switch for round cylinders Schematic symbol: Pneumatic cylinder switch

Materials:

Plastic

Temperature range:

-15 to +60 °C

Media:

unoiled, filtered compressed air

Application:

The cylinder switch is a 3/2-way valve controlled via the magnetic piston of a cylinder. It can be used to control pneumatic circuits, where it is very difficult to design and fit a limit switch. In contrast to a pneumatic sensor fitting, similar to an electric cylinder switch, a pneumatic cylinder switch allows querying the exact position of the piston and need not be positioned in the end position.

Warning: Order accessories at the same time!

1 unit tension band

{{ $t('shop.all.dokumente') }}:

  • Catalogue page Atlas 9 (Page 888) atlas9_seiten/888.pdf
    Documentation: Tips for selecting the right cylinder switch doku/leitfadenzurauswahldesrichtigenzylinderschalters.pdf
{{ $t('shop.display.artikelgruppe.mehr_informationen') }} {{ $t('shop.display.artikelgruppe.weniger_informationen') }}

{{ $t('shop.display.artikelgruppe.filtern') }}

{{ $t('shop.display.artikelgruppe.kein_eintrag') }}
Pneumatic cylinder switch for round cylinder up to Ø 100, Type H:
{{ $t('shop.all.artikelgruppe_n_von_m_artikeln', { anzahlArtikelAngezeigt: anzahlArtikelAngezeigt, anzahlArtikelGesamt: anzahlArtikelGesamt} ) }}
138,87€ incl. VAT
74,08€ incl. VAT
