Bulkhead coupling socket (NW5) 4mm hose, PVDF

Type POM:


Materials:
Body: POM black, springs and valve: Stainless steel 1.4310, seals: NBR

Temperature range:
-20°C to max. +80°C

Operating pressure:
0 - 10 bar

Flow of air (water)**
550 l/min (7 l/min), in conjunction with blocking coupling plug -BA: 310 l/min (2.7 l/min)

Type PVDF:


Materials:
Body: PVDF natural, springs and valve: stainless steel 1.4571, seals: FKM

Temperature range:
-20°C to max. +120°C

Operating pressure:
0 - 8 bar

Flow of air (water)**
550 l/min (7 l/min), in conjunction with blocking coupling plug -BA: 310 l/min (2.7 l/min)

Note:
Coupling sockets and coupling plugs (open or locking) can be combined as required.

Compatible with*:
Rectus (21, 90), Camozzi, EWO, KANI

Material	PVDF
Hose diameter (inner) [mm]	4
A	M 10x1
Emax [mm]	13
Temperature range [°C]	-20 to +120
Operating pressure [bar]	0 - 8

{{ $t('shop.all.gewicht') }}	18 g / pcs
{{ $t('shop.all.gtin') }}	4050571401344
{{ $t('shop.display.artikel.zollwarennummer') }}	84812090
{{ $t('shop.display.artikel.rohskonform') }}	{{ $t('shop.all.ja') }}
{{ $t('shop.all.hersteller') }}	Parker
